Futura Metalstar P One Basic 23-4. Four Sided Planer

New

Available to order

£26,900.00

(£32,280.00 inc VAT)

Futura P One Basic 23-4. 100% Italian Manufactured Four Sided Planer - High Spec: Single Piece fabricated base, In-feed table with ground steel bars, Independent motor unit to each spindle, Poly “V” Drive Belts instead of flat belt, Powered rise and fall, Pneumatic Pressures to the Feed Rollers, Pre – Planer roller with pneumatic exclusion, Feed Rollers driven by Double Chain Drive and Cardan Joints, Numerical Readout to the Thickness & Width, Bed lubrication pump to reduce friction when feeding, Air Blowers to reduce feeding when feeding timber, Tersa cutter blocks 4 Knife, Min Working Width Kit with 10mm rollers.

  • Max Finished Size Width

    220mm

  • Min Working Width

    25mm

  • Min Working Width with 10mm Roller Kit

    15mm

  • Max Working Height

    130mm

  • Min Working Height

    8mm

  • Min Work Piece Length

    250mm

  • Spindle Speed

    6000rpm

  • Shaft Size

    40mm

  • Indeed Table

    2300mm

  • Feed Speed

    7 & 14 m/min

  • Feed Roller Ø

    130mm

  • Motors

  • Planer Spindle Motor

    7.5hp

  • RH Spindle Motor

    5.5hp

  • LH Spindle Motor

    5.5hp

  • Upper Horizontal Motor

    7.6hp

Download Brochure
